Singhui သည် အရည်အသွေးမြင့်မားပြီး ကျိုးကြောင်းဆီလျော်သောစျေးနှုန်းဖြင့် ထုတ်လုပ်သူ China Single Arm PTP MDF CNC Drilling Woodworking Center မှ ပရော်ဖက်ရှင်နယ်ခေါင်းဆောင်တစ်ဦးဖြစ်သည်။ ကျွန်ုပ်တို့ကို ဆက်သွယ်ရန် ကြိုဆိုပါတယ်။
Singhui is a professional leader China Single Arm PTP MDF CNC Drilling Woodworking Center manufacturers with high quality and reasonable price. Welcome to contact us.
The machine is designed to meet diverse complicated processing requirements, highly versatile with routing, drilling, cutting, side milling, sawing and other functions. At the same time, the machine is also equipped with 8-slots carousel tool changer, tool changes to be performed within 8 seconds. Vacuum table fitted with suction cups. Cropping the full sheet to your ideal size, routing, drilling, sawing, cutting, and milling—multiple functions, all in one. Easy for loading and unloading, spend less time but get more out of it.
စီးရီး |
E6-1230D |
E6-1252D |
ခရီးသွားအရွယ်အစား |
3400*1640*250mm |
5550*1640*250mm |
အလုပ်အရွယ်အစား |
3060*1260*100mm |
5200*1200mm |
စားပွဲအရွယ်အစား |
3060*1200mm |
5200*1200mm |
ကူးစက်ခြင်း |
X Y rack and pinion ဒရိုက်၊ Z ဘောလုံး ဝက်အူဒရိုက်၊ |
|
ဇယားဖွဲ့စည်းပုံ |
အိုးများနှင့် သံလမ်းများ |
|
Spindle စွမ်းအား |
9.6 / 12KW HSD |
|
ဗိုင်းလိပ်တံအရှိန် |
24000r/မိနစ် |
|
ခရီးအမြန်နှုန်း |
80m/min |
|
အလုပ်လုပ်နှုန်း |
20m/min |
|
ကိရိယာ မဂ္ဂဇင်း |
ချားရဟတ် ၈ ပေါက် |
|
ဘဏ်ထည့်သွင်းမှု |
9 ဒေါင်လိုက်+ 6 အလျားလိုက်+ လွှဓါး ၁ ခု |
|
မောင်းနှင်မှုစနစ် |
Yaskawa |
|
ထိန်းချုပ်ကိရိယာ |
OSAI/ Syntec |
|
ဓာတ်အား |
AC 380/ 3P/ 50HZ |
